• Force Range: 300 kN (67442 lbf)
• Crosshead Speed: 0.01 to 255 mm/min (0.0004 to 10.04 in/min)
• Speed Accuracy: < 0.1% at steady state
• Travel: 1200 mm (47.24 in)
• Load Resolution: < 0.005% of loadcell used (Maximum)
• Extension Resolution: < 0.1 micron
• Data Sampling Rate: 100 Hz
• Extensometer Inputs:

Standard 0 - 10V dc analogue

Standard 0 - 1V dc analogue input and Strain Gauge

• Data Outputs Digital: RS232, Analogue - 10V dc max
• Load Measuring System: Exceeds the requirements of BS EN ISO 7500 1999, Class 0.5, ASTM E4, DIN 51221.
• Analysis Software: NEXYGEN MT Data Analysis Software and Ondio™ Applications Builder Software (Optional)
• Supply Voltage: 115/230V ac ± 10% 50 - 60 Hz
• Weight: 1200 kg (2646 lb)
• Width Between Columns: 620 mm (24.41 in)
• Operating Temp: 5° to 35°C (40°F to 95°F)
• Simple to set up, operate and maintain
• High accuracy load measurement (0.5% of reading)
• Rapid data acquisition
• Extension resolution better than 0.1 micron
• Capable of full load at full speed
• Exceeds national and international standards
• Constant load
• Large working area
• Multi lingual display options
• Multi unit display options
• Full PC integration
• Wide selection of load cells, grips, jigs & accessories
